Preparation
2
rearfront
control panel
handle
(both sides)
horizontal louver
blade
Caster
power plug socket
power cord buckle
bottom tray
drain outlet
power cord outlet
upper air filter
(behind the grille)
upper air intake
air outlet
lower air filter
lower air intake
drain outlet
Panel
