13
SE45-R2
SE45-R2 Specications
Performance Specications
Rated Pull 4,500 lbs (2041 kg)
Gear Reduction Ratio 166:1
Motor Permanent Magnet
1.7 HP (DC 12V)
Drum Size 2.0” (D) x 3.19” (L)
50.8 mm (D) x 81.0 mm (L)
Synthetic Cable 15/64” (D) x 38.0’ (L)
6 mm (D) x 11.6 m (L)
(35 useable feet with ve
wraps on the winch drum)
Weight 33.5 lbs. (complete kit)
Height 4.82 inches (122.5 mm)
Width 4.55 inches (115.5 mm)
Length 14.6 inches (371 mm)
Bolt Pattern 4-7/8” x 3” (124mm x 76 mm)
Line Speed and Motor Current (First Layer)
Line Pull Max lbs 0 1000 2000 3000 4500
kgs 0 454 907 1361 2041
Line Speed
(12 VDC)
FPM 12.8 9.8 8.5 6.9 4.6
MPM 3.9 3.0 2.6 2.1 1.4
Max Current amps 28 80 130 180 280
Cooling Time minutes 5 5 5 5 5
Line Pull and Cable Capacity
Layers of cable on drum 1 2 3 4
Max pulling capacity per
layer
lbs 4500 3715 3163 2754
kgs 2041 1685 1435 1249
Cable capacity
per layer
ft 7.6 16.8 27.6 38
m 2.3 5.1 8.4 11.6
