KFI STEALTH SE45-R2 User Manual

15
SE45-R2
SE45-R2 Specications
Winch Parts List
No.
Part# Description
Qty.
01 450100 Motor Assembly 1
02 450026-B Bolt M4 x 25 - Black Zinc 2
03 450027-B Washer Φ4, Flat - Black Zinc 2
04 450001 Coupling, 1 1
05 450002 Brake Spring 1
06 450003 Coupling, 2 1
07 400010-BF Tie Bar Φ8 - Black Flat 1
08
400200A-
BF
Drum Assembly - Black Flat 1
09 450004-BF
Gear Housing/End Bearing -
Black Flat
1
10 450005-A Gear Ring 1
11 450006 Gear Carrier Assembly,Output 1
12 450007
Gear Carrier
Assembly,Intermediate
1
13 450008 Gear Carrier Assembly,Input 1
14 450009 Gear-Input, Sun 1
15 450010 Gear, Fixed 1
16 450034 Clutch Bushing 1
17 250011 Retaining Ring Clip 1
18 250017-B
Locking Washer Φ6 - Black
Zinc
1
19 450030-B
Cap Screw M6 x 16 - Black
Zinc
1
20 250002-B Washer Φ6, Flat - Black Zinc 10
21 450011-B Bolt M6 x 25 - Black Zinc 4
22 450012-B Bolt M6 x 100 - Black Zinc 2
23 250016-BF Clutch Cap - Black Flat 1
24
GB2760BB-
16002SS
Radial Ball Bearing 16002
Sealed
1
25 450033-BF Clutch Cover - Black Flat 1
26 250012 Spring 1
27 450032 Cam Clutch Gear 1
28 250019 Axis Support Bushing 1
29
GB2760BB-
06002SS
Radial Ball Bearing 6002
Sealed
1
30 450013 Seal 2
31 450014 Friction Washer 2
32 450015 Retaining Ring 1
33 450016 O-Ring Seal 1
34 450017 Drum Bushing 2
35 450031
Cross Recess Set Screw
M5 x 8
1
No.
Part# Description
Qty.
36 400018 Haxagonal Shaft 1
37 450029 Shaft Spring 1
38 400008-BF Tie Bar Φ10 - Black Flat 2
39 250061 Terminal Protector 8
40 250062 Wire Tap 2
41 250068-B Locking Nut M6 - Black Zinc 4
42 250067-B
Washer Φ6, Locking - Black
Zinc
4
43 250065-B Screw M6 x 25 - Black Zinc 4
44 250069-B
Screw M6 x 1.0 x 20 - Black
Zinc
2
45 ATV-CONT Contactor 1
46 UTV-DRS-K
UTV-DRS Wire Harness
Assembly
1
47 UTV-DRS
UTV Dash Mounted Rocker
Switch
1
48 ATV-SCHS Split Cable Hook Stopper 1
49 250071-B Nut M5 - Black Zinc 2
50 250064 Hand Remote 3-Pin Connector 1
51 250049-B Washer Φ5, Flat - Black Zinc 2
52 250048-B Bolt M5 x 25 - Black Zinc 2
53 250059-B Hand Remote Assembly - Black 1
54 450028-B Bolt M8 x 30 - Black Zinc 4
55 250032-B Bolt M8 x 25 - Black Zinc 4
56 250063-B
Washer Φ8, Locking - Black
Zinc
4
57 250070-B Washer Φ8, Flat - Black Zinc 4
58 100495 Mounting Channel - Black Flat 1
59 250033-B Bolt M10 x 20 - Black Zinc 2
60 SE-RF
Roller Fairlead - Black Flat,
POM Rollers
1
61 250035-B
Washer Φ10, Locking - Black
Zinc
2
62 250036-B Locking Nut M10 - Black Zinc 2
63 400015-B Winch Wires - Black 2
64 400016-B Battery Wires - Black 2
65 SYN23-S38 Synthetic Rope 15/64” x 38ft 1
66 SE-HOOK 1/4” Clevis Hook - Black 1
67 250030-B Strap - Black 1
68 500016 Square Nut 4
69 500017 Elastic Cylindrical Pin Φ3x 14 4
100 SE-U-CAPKIT
Motor Endcap w/ Brushes 1
