Page 4
ITEM PART# DESCRIPTION QTY.
1 61201 TIGERTAIL XT BASE 1
2 101132 XT BASE HOOK ADJUSTER 1
3 41019 SPOOL 1
4 P800343 SPOOL SPACER 2
5 41022 SHAFT SEAL 1
6 41024 2-046 BUNA-N O-RING 70D BLACK 1
7 41027 SPRING COVER ASM 1
7.1 41025 SPRING COVER 1
7.2 41026 TIGERTAIL SPRING 1
8 71206 XT SHAFT 1
9 101121 KFI TIGERTAIL ROPE ASSEMBLY 1
9.1 101122-15 TIGERTAIL XT ROPE 1
9.2 41013 7/16" WIRE ROPE THIMBLE 1
9.3 41011 TOW HOOK #12 ZINC 1
10 CB-ZP-1024-0_63 #10-24 x 5/8" CARRIAGE BOLT, STEEL, ZINC 6
11 HNNL-ZP-1024 #10-24 HEX NUT NYLOCK, STEEL, ZINC 8
12 FW-SAE-ZP-10 #10 FLAT WASHER, SAE, STEEL, ZINC 2
13 HK-306 HARDWARE KIT 1
13.1 CB-ZP-0500-13-1_25 1/2-13 x 1 1/4 CARRIAGE BOLT, STEEL, ZINC PLATED 4
13.2 FW-SAE-ZP-0500 1/2" FLAT WASHER, SAE, STEEL, ZINC 4
13.3 HN-ZP-0500-13 1/2"-13 HEX NUT, STEEL, ZINC 4
14 CB-ZP-1024-0_75 #10-24 x 3/4” CARRIAGE BOLT, STEEL, ZINC 2
