No. Fuse rating Symbol Fuse Name Protected component
25 7.5A
MEMOR
Y
2
MEMORY 2 Immobilizer Module (W/O Smart Key)
26 7.5A
MEMOR
Y
1
MEMORY 1
Driver/Passenger Outside Mirror (Folding), Driver/Passenger Smart Key Outside Handle,
Driver IMS Module, Center Facia Switch, Instrument Cluster, Tire Pressure Monitoring Module,
BCM, A/C Control Module, ICM Relay Box (Outside Mirror Folding/Unfolding Relay),
Ignition Key ILL. & Door Warning Switch, Rear Parking Assist Switch,
Data Link Connector, Buzzer
27 10A
BRAKE
SWITCH
BRAKE
SWITCH
Smart Key Control Module, Stop Lamp Switch
28 7.5A
CLUSTER
CLUSTER Instrument Cluster, Digital Clock
29 7.5A
1
POWER
STEERING
EPS Unit
30 7.5A
SPAR
E
SPARE -
31 7.5A START
Start Relay, ECU, Ignition Lock Switch, Transaxle Range Switch,
TCU, Smart Key Control Module
32 15A
MULTI
MEDIA
MULTI MEDIA
A/V & Navigation Head Unit (W/O ISG), Audio (W/O ISG),
DC-DC Convertor (With ISG), Digital Clock
33 10A
SPAR
E
SPARE -
34 25A
1
PDM 1 Smart Key Control Module
35 15A
POWER
OUTLET1
P/OUTLET 1 Front Power Outlet
