763
Maintenance
No. Fuse rating Symbol Fuse Name Protected component
14 7.5A A/CON Cluster Ionizer, A/C Control Module, Blower Relay, PTC Relay
15 7.5A
IG2
IG2
ICM Relay Box (Head Lamp Washer Relay), Rain Sensor, BCM, Electro Chromic Mirror,
Panorama Sunroof, Smart, Key Control Module, Passenger Seat Warmer Module,
Driver Seat Warmer Module
16 10A HTD MIRR Driver/Passenger Outside Mirror, ECU, A/C Control Module
17 7.5A
INTERIOR
LAMP
Glove Box Lamp, Luggage Lamp, Vanity Lamp LH/RH, Room Lamp,
Overhead Console Lamp
18 7.5A
2
PDM 2 Smart Key Control Module, Start/Stop Button Switch
19 7.5A B/HORN ICM Relay Box (Burglar Alarm Horn Relay)
20 20A SUNROOF Panorama Sunroof
21 10A
MODULE
2
MODULE 2
Electric Parking Brake Module, DC-DC Convertor (With ISG),
Head Lamp Leveling Device Switch, A/C Control Module, Rear Parking Assist Sensor,
Smart Parking Assist Control Module, Head Lamp LH/RH, ATM Shift Lever IND.,
Center Facia Switch, Crash Pad Lower Switch, Driver/Passenger Seat Warmer Module,
Driver IMS Module
22 15A HTD STRG Steering Wheel Heater
23 20A
IG1
IG1 E/R Fuse & Relay Box (ECU4, B/UP LAMP, ABS3, TCU2 FUSE)
24 25A
FRT
WIPER Wiper Relay , ICM Relay Box (Rain Sensor Relay), Front Wiper Motor
