775
Maintenance
Fuse Fuse rating Symbol Fuse Name Protected component
MULTI
FUSE
80A
1
POWER
STEERING
EPS Unit
60A
B+1
B+1
Inner Fuse Panel, IPS1 (H/LAMP HI LH,H/LAMP LOW LH, FRT TURN LH, POSITION LAMP LH),
IPS2 (STATIC BENDING LAMP LH/RH, DRL LH/RH)
40A
1
ABS1 ESC Control Module, ABS Control Module
40A
2
ABS2 ESC Control Module, ABS Control Module, Multipurpose Check Connector
40A
IG2
IG2
W/O Smart Key : Ignition Switch, START RELAY
With Smart Key : IG2 RELAY, START RELAY, INNER FUSE PANEL ( Fuse No. - 14/24/22/15/10)
60A
B+2
B+2
Inner Fuse Panel, IPS3 (H/LAMP HI RH,H/LAMP LOW RH, FRT TURN RH,
POSITION LAMP RH), IPS4 (FRT FOG LAMP LH/RH, REAR TURN LH/RH),
IPS5 (REAR FOG LAMP, INT TAIL LAMP)
FUSE
40A RR HTD RR HTD RELAY , RR HTD
40A
IG1
IG1
W/O Smart Key : Ignition Switch
With Smart Key : IG1 RELAY, ACC RELAY, INNER FUSE PANEL (Fuse No. - 38/36/21/37/
23/29/28, Fuse No. - 13/8/35)
30A
1
EPB1 Electric Parking Brake Module
30A
2
EPB2 Electric Parking Brake Module
50A C/FAN C/FAN LO RELAY, C/FAN HI RELAY
15A DEICER ICM Relay Box (Front Deicer Relay)
15A
STOP
LAMP
STOP LAMP Stop signal electronic module
Engine compartment main fuse panel (for diesel engine)
