Maintenance
787
Engine compartment fuse panel
(Diesel engine only)
NOTICE
The actual fuse/relay panel label may
differ from equipped items.
Description Fuse rating Protected Component
80A Glow Unit
PTC 1 50A PTC 1 Relay, PTC HEATER
PTC 2 50A PTC 2 Relay, PTC HEATER
PTC 3 50A PTC 3 Relay, PTC HEATER
OGD071024
OJD075102L
JD PE eng 7.QXP 1/28/2016 5:39 PM Page 78
