Kia Ceed 2017 - Page 606

Maintenance
887
Vehicle
condition
H1 H2
H3
W1 W2
W3
FOG ONLY
FOG+DRL FOG ONLY FOG+DRL
Without
driver
689/699/684
(27.1)/(27.5)/(26.9)
646/656/641
(25.4)/(25.8)/(25.2)
345/355/340
(13.6)/(13.9)/(13.4)
328/338/323
(12.9)/(13.3)/(12.7)
1,300
(51.2)
1,049
(41.3)
1,346
(52.9)
1,334
(52.5)
With driver
680/690/675
(26.7)/(27.2)/(26.6)
637/647/632
(25.1)/(25.5)/(24.9)
336/346/331
(13.2)/(13.6)/(13.0)
319/329/314
(12.6)/(12.9)/(12.4)
■ 3,5 Door and Wagon
■ 3 and 5Door (for T-GDI)
Vehicle
condition
H1 H2 H3 W1 W2 W3
Without
driver
689/699/684
(27.1)/(27.5)/(26.9)
646/656/641
(25.4)/(25.8)/(25.2)
305/315/300
(12.0)/(12.4)/(11.8)
1,300
(51.2)
1,049
(41.3)
1,332
(52.4)
With driver
680/690/675
(26.7)/(27.2)/(26.6)
637/647/632
(25.1)/(25.5)/(24.9)
296/306/291
(11.7)/(12.0)/(11.5)
■ 3,5 Door and Wagon (for Sports Pack)
Unit: mm (in)
Vehicle
condition
H1
H2
H3
W1 W2
W3
FOG ONLY FOG ONLY
Without
driver
689/699/684
(27.1)/(27.5)/(26.9)
646/656/641
(25.4)/(25.8)/(25.2)
308/318/303
(12.1)/(12.5)/(11.9)
1,300
(51.2)
1,049
(41.3)
1,308
(51.5)
With driver
680/690/675
(26.7)/(27.2)/(26.6)
637/647/632
(25.1)/(25.5)/(24.9)
299/309/294
(11.8)/(12.2)/(11.6)
