What to do in an emergency
Technical Data
System voltage : DC 12 V
Working voltage : DC 10 - 15 V
Amperage rating : max. 15 A
Suitable for use at temperatures :
-22 ~ +158°F (-30 ~ +70°C)
Max. working pressure :
87 psi (6 bar)
Size
Compressor : 6.6 x 5.9 x 2.7 in.
(168 x 150 x 68 mm)
Sealant bottle : 4.1 x ø 3.3 in.
(104 x ø 85 mm)
Compressor weight :
2.31 lbs (1.05 kg)
Sealant volume :
18.3 cu. in. (300 ml)
Sealant warranty :
5 years (sealant.)
CAUTION - Tire pressure
sensor
When you use the Tire Mobility
Kit including sealant not
approved by Kia, the tire pres-
sure sensors may be damaged
by sealant. The sealant on the
tire pressure sensor and wheel
should be removed when you
replace the tire with a new one
and inspect the tire pressure
sensors at an authorized dealer.
