Specifications, Consumer information, Reporting safety defects
28
ENGINE
Item 2.0 MPI
2.0 GDI 1.6 Turbo GDI
Displacement [cu.in(cc)] 121.99 (1,999) 121.99 (1,999) 97.1 (1,591)
Bore x Stroke [in(mm)] 3.19 x 3.82 (81 x 97) 3.19 x 3.82 (81 x 97) 3.03 x 3.36 (77 x 85.4)
Firing order
1 → 3 → 4 → 21 → 3 → 4 → 21 → 3 → 4 → 2
No. of cylinders 4, In-line 4, In-line 4, In-line
DIMENSIONS
Item in (mm)
Overall length
4 Door 179.5 (4,560)
5 Door 171.3 (4,350)
Overall width 70.1 (1,780)
Overall height
4 Door 56.3 (1,430)
5 Door 57.1 (1,450)
Front tread
195/65 R15 (Steel) 61.5 (1,563)
205/55 R16 (Steel) 61.1 (1,553)
205/55 R16 (Alloy) 61.2 (1,555)
P215/45 R17 (Alloy) 61.3 (1,557)
P225/40 R18 (Alloy) 60.8 (1,545)
Rear tread
195/65 R15 (Steel) 62.0 (1,576)
205/55 R16 (Steel) 61.6 (1,566)
205/55 R16 (Alloy) 61.7 (1,568)
P215/45 R17 (Alloy) 61.8 (1,570)
P225/40 R18 (Alloy) 61.3 (1,558)
Wheelbase 106.3 (2,700)
