Fuse Name Fuse rating Circuit Protected
FUSE
IP B+ 3 50A
I/P Junction Box (Power Connector (ROOM LP 10A), SUNROOF 20A, DR LOCK 20A IPS 1,
IPS 3, ARISU 1)
IGN 1 40A Fuse & Relay Box (PDM 1(ACC) Relay, PDM 2(IG 1) Relay), Ignition Switch
EMS 40A EMS Box (HORN 15A, ECU 3 10A, ECU 1 30A, F/PUMP 20A)
ECU 4 10A PCM
TCU 2 15A Back-Up Lamp Switch, Vehicle Speed Sensor, Transaxle Range Switch
ABS 3 10A
E/R Fuse & Relay Box (HAC Relay), Stop Lamp Switch, ESC Module,
Multipurpose Check Connector
B/UP LP 10A
A/V & Navigation Head Unit, Audio, Electro Chromic Mirror, BCM,
Rear Combination Lamp(In) LH/RH
A/CON 10A A/C Control Module
