7-82
Maintenance
Fuse Name Fuse rasting Circuit Protected
Stop Lamp 15A Stop Signal Electronic Module
Brake SW 10A Stop Lamp Switch, Smart Key Control Module
AAF 10A Not Used
Injector 1 15A Injector Drive Box
SMK (IGN1) 40A E/R Fuse & Relay Box LH (RLY.5)
ESC 1 40A ESC Control Module
ALT 200A E/R Fuse & Relay Box LH (Fuse : F9, F15, F16, F18, F19), Alternator
Cooling 70A E/R Fuse & Relay Box LH (RLY.6)
SMK (IGN2) 30A E/R Fuse & Relay Box LH (RLY.3)
ESC 2 40A ESC Control Module
Diagnosis 25A Multipurpose Check Connector
H/Lamp Washer 25A Not Used
Battery 3 40A Smart Junction Box (Fuse : F5, F6, F8, F9, F10)
SMK (ACC) 40A E/R Fuse & Relay Box LH (RLY.9)
TCU 1 10A ECM, Transmission Range Switch, Transmission Park Postilion Sensor & Switch
ESC 3 10A Steering Angle Sensor, ESC Control Module
B/UP Lamp 1 10A E/R Fuse & Relay Box LH (RLY.4)
