Maintenance
7
7-83
Fuse Name Fuse rasting Circuit Protected
Vaccum Pump 1 10A E/R Fuse & Relay Box LH (RLY.10), Vaccum Pump Switch
Vaccum Pump 2 20A E/R Fuse & Relay Box LH (RLY.10)
ECU 1 10A ECU
EHPS 1 10A EHPS Module
Inhibitor 2 10A A/T Console Switch, Electric ATM Shift Lever
Washer 15A E/R Fuse & Relay Box LH (RLY.8)
Wiper 2 10A E/R Fuse & Relay Box LH (RLY.1)
B/UP Lamp 2 10A
Back View Camera & Back-Up Lamp, A/T Console Switch, Electro Chromic Mirror, A/V & Navigation Head
Unit
