Fuse Fuse Name Fuse rasting Circuit Protected
METAL
CORE
BLOCK
(PCB #1)
Sensor 3 10A Rear Smart Junction Box (Fuel Pump Relay)
P/Door PASS 15A Passenger Door Latch
SPARE 15A Spare
Deicer 15A Metal Core Block (PCB #1) (Front Deicer Relay)
Ignition Coil 20A Ignition Coil #1~6, Ignition Coil #1~8, Condenser #1, #2
Horn 15A Metal Core Block (PCB #1) (Horn Relay)
Sensor 2 10A Mass Air Flow Sensor, Oxygen Sensor #1~4, E/R Fuse & Relay Box LH (RLY.6)
Sensor 4 15A CMP Sensor #1~4
Wiper 3 30A Wiper Motor
ECU 3 30A Metal Core Block (PCB #1) (ECU Main Relay)
ECS 2 40A Metal Core Block (PCB #1) (Air ECS Relay)
METAL
CORE
BLOCK
(PCB #2)
Sensor 1 15A
Purge Control Solenoid Valve, ECM, Variable Intake Solenoid Valve,
Oil Control Valve #1~4
Injector 2 15A Injector #1~6, Injector #1~8
SPARE 10A Spare
SPARE 20A Spare
SPARE 10A Spare
