7-86
Maintenance
Fuse Fuse Name Fuse rasting Circuit Protected
METAL
CORE
BLOCK
(PCB #2)
A/CON 2 10A A/C Control Module
Cruise 10A Smart Cruise Control Radar
TCU 2 15A TCM
ECU 2 10A ECM
Blower 40A Metal Core Block(PCB) (Blower Relay)
Start 1 30A E/R Fuse Relay Box LH (RLY.2)
MULTI
FUSE
Presafety Seat
Belt DRV
40A Driver Seat Belt Pretensioner
Presafety Seat
Belt PASS
40A Passenger Seat Belt Pretensioner
Battery 2 60A Smart Junction Box (Fuse : F13~20, F23, F24, F27, F28, IPS5~8, Arisu-LT2)
Battery 1 60A Smart Junction Box (Fuse : F38, IPS1, 3, Arisu-LT1, Leak Current Autocut Device)
EHPS 2 80A EHPS Module
FUSE
Battery 4 60A Metal Core Block (PCB #1) (Fuse : F2, F4, F6, F10, F11, F12)
Battery 5 60A Metal Core Block (PCB #2) (Fuse : F7, F11)
