2
KX.1-SERIES AMPLIFIERS
OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no items
behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open
ventilation for the amplifi er. If possible, mount the amplifi er in the climate-controlled passenger compartment. Drill
four holes using a 7/64” (3mm) bit and use the supplied #8 screws to mount the amplifi er.
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Model Number:
Serial Number:
Model: KX400.1 KX800.1 KX1200.1 KX1600.1 KX2400.1
RMS Power
@ 14.4V, 4 mono, d 1% THD+N
@ 14.4V, 2 mono, d 1% THD+N
200W x 1
400W x 1
400W x 1
800W x 1
600W x 1
1200W x 1
800W x 1
1600W x 1
1200W x 1
2400W x 1
Length | in [cm] 8 [20.4] 9 9/16 [24.4] 9 9/16 [24.4] 11 3/16 [28.4] 15 1/2 [39.4]
Specifi cations common to all models:
Height | in [cm] 2 1/8 [5.5]
Width | in [cm] 8 5/16 [21]
Frequency Response ± 1dB 10Hz–160Hz
Signal-to-noise Ratio >95dB, A-weighted, re: rated power
Input Sensitivity Low Level: 125mV–5V
High Level: 250mV–10V
Electronic Crossover Variable Lo-pass 40Hz–160Hz, 24dB/octave
Bass Boost Parametric 20-80Hz; Variable Q: 1 to 5; Variable Boost, 0-18dB
Subsonic Filter Variable 10–80Hz, 24dB/octave
Remote Bass Yes [included]
Pro Tip: To get the best performance from your new KICKER Amplifi er and extend the warranty by 1 year, use
genuine KICKER accessories and wiring.
MODEL: KX400.1 / KX800.1 / KX1200.1 / KX1600.1 / KX2400.1
2013 KX Mono Amps Rev G.indd 2 11/13/2012 2:17:11 PM
