KXM.5-SERIES AMPLIFIERS
OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no
items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of
open ventilation for the amplifi er. Drill four holes using a 7/64” (3mm) bit and use the supplied #8 screws
to mount the amplifi er.
PERFORMANCE
MODEL: KXMA800.5
IMPORTANT SAFETY WARNING
PROLONGED CONTINUOUS OPERATION OF AN AMPLIFIER, SPEAKER, OR SUBWOOFER IN
A DISTORTED, CLIPPED OR OVER-POWERED MANNER CAN CAUSE YOUR AUDIO SYSTEM
TO OVERHEAT, POSSIBLY CATCHING FIRE AND RESULTING IN SERIOUS DAMAGE TO YOUR
COMPONENTS AND/OR VEHICLE. AMPLIFIERS REQUIRE UP TO 4 INCHES (10CM) OPEN
VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1 INCH (2.5CM)
CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY SURFACE.
Model: KXMA800.5
RMS Power, AMP1 and AMP2
@ 14.4V, 4Ω stereo, ≤ 1% THD+N
@ 14.4V, 2Ω stereo, ≤ 1% THD+N
@ 14.4V, 4Ω mono, ≤ 1% THD+N
50W x 4
100W x 4
200W x 2
RMS Power, SUB channel
@ 14.4V, 2Ω mono, ≤ 1.5 % THD+N
@ 14.4V, 4Ω mono, ≤ 1.5 % THD+N
400W x 1
200W x 1
Length [in, cm] 12-3/4, 32.4
Height [in, cm] 2-1/8, 5.5
Width [in, cm] 8-5/16, 21
Frequency Response [Hz] AMPS 1-2: 10Hz–20kHz
SUB: 10Hz–160Hz
Signal-to-Noise Ratio [dB] >95dB, A-weighted, re: rated power
Input Sensitivity 250mV–10V
Selectable Electronic Crossover AMP 1: OFF/HP/LP, variable 10–5,000Hz with 10X switch;
24dB/octave
AMP 2: OFF/HP/LP/BP, variable HP 10–500Hz,
variable LP 40–5,000Hz with 10X switch; 24dB/octave
SUB: Variable LP 40–160Hz; 24dB/octave
KickEQ™ Parametric Bass Boost Boost - Variable 0-18db; Center Frequency - 40Hz
Subsonic Filter Variable 10–80Hz; 24dB/Octave
NOTE: 2017 KXM amplifi er subwoofer channels are 1Ω stable - power rating equivalent to 2Ω operation, +/- 10%
