14. Pop open a cold beverage and admire your work!
9
SoloX Subwoofer
Mounting
12. Insert the SPAIR back into
the BAM. Be careful not to dam-
age the voice coil. The double
threaded studs and the ARCTIC
Cap will help to center SPAIR as
you lower it into the BAM.
When properly aligned these
assemblies slide together easily.
13. Using the 1/4”-20 acorn head
nuts and eight bolts secure the
SPAIR to the BAM. When tight-
ening the nuts follow the pat-
tern drawn below. This will
insure a proper fit.
ATTENTION!
Follow the pattern, hand tight-
ening each, then go back and
tighten using the same pat-
tern.
