Tip! This step may be easier to perform
if the quad is upside down.
ATTACH THE FRONT WHEELS
Using the spanner, remove the nut from the axle. Then remove the small washer.
Leave the large washer on the axle.
Slide the wheel all the way onto the axle unl it meets the large washer.
All the wheels are idencal and can be placed on any axle.
Slide the small washer onto the axle.
Place the nut onto the end of the axle and ghten with the spanner.
Line up the tabs on the hubcap with the slots in the wheel. Press the hubcap into
the wheel unl in snaps into place.
Repeat steps 2-5 for the remaining front wheel.
6
Spanner
Front axle
Large washer
1
3
2
5 4
Small
washer
NutHubcap
