15
CAUTION: This unit is sealed. The cover is not removable.
After selecting the proper smoke alarm location as described in Section 4, attach the mounting bracket to the
ceiling as shown in Figure 8-A. Use the screws and anchors provided to secure the mounting bracket (Use
5mm drill bit for anchors).
CAUTION! If the battery compartment is empty, the unit will not attach to the mounting bracket.
Please installing the battery at rst. Alignment marks are provided on the edge of the mounting bracket and the
alarm. Place the alarm on the mounting bracket with the alignment marks lined up(Figure 8-B) and rotate the
alarm clockwise (as indicated on the alarm cover) until the alarm snaps into place.
After installation/activation, test your alarm as described in Operation and Testing section.
