Kidde DM3000E User Manual

P/N 03-0210-501-0100-01 • ISS 06MAY19 3 / 16
Maintenance and testing
Maintenance
Inspect the unit regularly to ensure that it is free from dust and
physical damage. Do not modify internal wiring or circuitry.
Testing
To activate an alarm, push the resettable element or turn the
key clockwise (one click). To reset the device, turn the key
anticlockwise (one click). Reset the control panel after testing.
Replacing the resettable element
Replace the resettable element (or add the breakable element)
as follows:
1. Unlock and remove the front cover as described in
“Installation” on page 2.
2. Push the element up, and then pull it out (see Figure 5).
3. Replace the resettable element (or add the breakable
element, if required).
4. Replace the front cover.
Specifications
Electrical
Operating voltage
16 to 42 VDC
Current consumption
Standby
Alarm
200 µA
2.9 mA
Mechanical and environmental
IP rating
[1] IP67
Bac
kbox cable knockouts
Top
Bottom
1 × threaded knockout (MK20)
2 × threaded knockout (MK20)
Wire
diameter (terminal block)
Minimum
Maximum
0.404 mm (26 AWG)
2.05 mm (12 AWG)
Operating environment
Operating temperature
Storage temperature
Relative humidity
−25 to +72°C
−25 to +72°C
10 to 95% (noncondensing)
Colour
Red (RAL3028)
Weight [2]
252 g
Dimensions [2]
108 × 108 × 69 mm
[1] When used with the supplied
cable gland and plugs
[2] Including the backbox, excluding cable gland and plugs
Regulatory information
This section provides a summary on the declared performance
according to the Construction Products Regulation
(EU) 305/2011 and Delegated Regulations (EU) 157/2014 and
(EU) 574/2014.
For detailed information, see the product Declaration of
Performance (available at firesecurityproducts.com
).
EU compliance
Certification body
0370
Manufacturer
United Technologies Safety Systems,
80 Changjiang East Road,
QETDZ, Qinhuangdao, Hebei, China 066004.
Authorized EU manufacturing representative:
UTC Fire & Security B.V. Kelvinstraat 7, 6003
DH Weert, Netherlands.
Year of first CE
marking
2019
Declaration of
Performance number
03-0210-360-1100
EN 54
EN 54-11 Type A (Outdoor Use)
Product identification
DM3000E, DM3000ES06, DM3000ES18,
DM3000ES27
Intended use
See the product Declaration of Performance
Declared performance
See the product Declaration of Performance
European Union
directives
2014/53/EU (Radio Equipment Directive):
Hereby, UTC Fire & Security declares that this
device is in compliance with the essential
requirements and other relevant provisions of
Directive 2014/53/EU.
2012/19/EU (WEEE Directive): Products
marked with this symbol cannot be disposed
of as unsorted municipal waste in the
European Union. For proper recycling, return
this product to your local supplier upon the
purchase of equivalent new equipment, or
dispose of it at designated collection points.
For more information see:
http://www.recyclethis.info
.
Contact information and product
documentation
For contact information or to download the latest product
documentation, visit firesecurityproducts.com
.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND
INSTALLATION BY QUALIFIED PROFESSIONALS. UTC
FIRE & SECURITY CANNOT PROVIDE ANY ASSURANCE
THAT ANY PERSON OR ENTITY BUYING ITS PRODUCTS,
INCLUDING ANY “AUTHORIZED DEALER” OR
“AUTHORIZED RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE AND
SECURITY RELATED PRODUCTS.
