2. After selecting the proper smoke alarm location as described in Section 1, attach
the mounting bracket to the ceiling as shown in Figure 3. For wall mounting see
Figure 4. Place the mounting plate on the wall; be sure the “A” line is horizontal
(parallel to the floor). Use the screws and wall plugs provided to secure the mount-
ing bracket (use 3/16” drill bit for wall plugs).
3. This alarm has batteries permanently sealed inside the alarm no battery installation
or maintenance is necessary.
ACTIVATING THE ALARM
This model is equipped with a feature that automatically activates the alarm
when the alarm is mounted to the mounting bracket for the first time. Once
activated, the batteries will supply power to the alarm for the life of the
alarm (10 years). Be sure that the mounting bracket is mounted correctly
before installing the alarm on the mounting bracket.
1. To activate the alarm, install the alarm on the mounting bracket (Figure 6) and
rotate the alarm clockwise (as indicated on the alarm cover) until the alarm ratchets
into place (the ratcheting function allows for aesthetic alignment). NOTE: The
alarm will mount to the bracket in four (4) positions (every 90 degrees).
The alarm is now activated!
2. After installation/activation, test your alarm by depressing and holding down the
test button for a minimum of 5 seconds (or until the alarm sounds). This should
sound the alarm. CAUTION: Due to the loudness (85 decibels) of the alarm,
always stand an arms length away from the unit when testing.
TAMPER RESIST FEATURE
Smoke Alarm Tamper Resist Feature
This alarm is equipped with a tamper resist feature that helps prevent someone from
removing the unit from the mounting bracket. When activated, it can be very effec-
tive in preventing smoke alarm removal or tampering.
Activate the smoke alarm tamper resist feature by breaking off the four posts in the
square holes in the mounting bracket (see Figure 7). When the posts are broken off,
the tamper resist on the base is allowed to engage the mounting bracket. Rotate the
alarm onto the mounting bracket until you hear the tamper resist tab snap into place,
locking the alarm on the mounting bracket. Using the tamper resist feature will help
deter children and others from removing the alarm from the bracket. NOTE: To
remove the alarm when the tamper resist tab is engaged, press down on the tamper
resist tab and rotate the alarm in the direction indicated by the arrows on the cover of
the alarm (see Figure 8).
FIGURE 7 FIGURE 8
Location of Posts:
