BMA0804
Product Description
J
Page 11 / 12
2.60-80.804-01-EN | 2019-01-17
LED displays
LED CAN Bus
Status of inputs and outputs
Outputs:
- 0..100% green, the luminosity of the LED changes depending on the output signal,
100% = full luminosity
- In manual mode, the output LEDs additionally flash yellow
Inputs:
- Sensor value valid: LED lights up green:
- Sensor value outside the measuring range: LED lights up red
- No sensor (sensor type) configured: LED off
- Negative voltage at the input falsifies the measuring signal: all input LEDs light up red.
The affected input flashes red.
- The +10 V DC auxiliary voltage breaks down. Caused by incorrect wiring:
LEDs of the 0/2..10 V DC inputs lights up red.
LED status (combination
LED)
Meaning Cause
off Module not in operation No operating voltage or operating
voltage too low
Yellow on (green LED and red
LED on)
Module in operation, but
there is a bus error
no CAN communication
possible, module not
logged on
Bus line short circuit (with respect to
ground or each other),
Bus lines reversed or
interrupted
Address 00 (manual oper-
ation effective, functional
test possible)
Yellow flashing (green LED and
red LED flashing simultane-
ously)
Flashing rate 1 sec.
Address error, no bus
activity
Outside of address range #01..#63
address assigned multiple times
Green flashes and red LED off Module OK, bus activity
Red LED and green LED flash
alternately slowly
Flashing rate 6 sec.
Update is being trans-
ferred from DDC4000e to
module
Red LED permanent light Address 99 (deleting the
configuration, manual con-
trol effective)
