Kieback&Peter BMA0804 User Manual

Product Description
BMA0804
J
Page 4 / 12
2.60-80.804-01-EN | 2019-01-17
Connection terminal
■ Spring-loaded terminals, printers
■ All terminals can be inserted with conductor end sleeves of 10 mm length
■ Twisting two conductors is not permitted, twin wire-end ferrules can be used
Sensor Types
Input terminals
Terminal 21..32
and 51..59
Output terminals
Terminal 41..48
Supporting termi-
nals
Terminal 81..88
and 91..98
Bus terminals
Terminal 17..20
Stripping length 8..9 mm 10 mm 10 mm 10 mm
Conductor
cross-section sin-
gle-wire conductor
0.2..1.5 mm
2
0.08..2.5 mm
2
0.08..1.5 mm
2
0.2..1.5 mm
2
Conductor
cross-section
fine-wire conductor
0.25..1.5 mm
2
0.08..2.5 mm
2
0.08..1.5 mm
2
0.25..1.5 mm
2
Conductor
cross-section
fine-wire conductor
with wire-end fer-
rules
0.25..0.75 mm
2
0.08..2.5 mm
2
0.8..1.5 mm
2
0.25..0.75 mm
2
Recommended
crimping tools
Square
hex
Square
hex
Square
hex
Square
hex
Sensor type Measuring range
0(2) V..10 V 0..100 %
KP10 -50..+150 °C
KP250 -50..+150 °C
ML2 -50..+150 °C
Ni100 -50..+150 °C
Ni1000 (DIN) -50..+150 °C
Ni1000 (L&G) -50..+150 °C
NTC1,8K -50..+150 °C
NTC5K -50..+150 °C
NTC10K -40..+150 °C
NTC10KPRE -40..+150 °C
NTC20K -30..+150 °C
PT100 -100..+850 °C
PT1000 -100..+850 °C
Balco500 -40..+150 °C
Satchwell DC1100 -20..+120 °C
Satchwell DC1400 -40..+120 °C
Resistor (potentiometer) 0..500 k
