Kinco FV20-4T-0037G/0055L User Manual

Chapter 3 Wiring Guide of VFD
48
Category Terminals Name Function description Specification
Multi-
function
output
terminal
Y1
Open collector
output terminal
(High-speed
pulse) output
terminal
When defined as Open collector output
terminal,refer to the A6.14 for detail,When
defined as High-speed pulse output
terminal,refer to A6.27 for detail.Maximum
frequency could up to 100KHz
Optocoupler isolation output
Maximum working voltage.30v
Maximum output current.50mA
Power
supply
+24V
+24V power
supply
Providing +24V power for others Maximumoutputcurrent.200mA
Common-
port
PLC
Common port
of
multi-function
input
Common port of Multi-function input
(Short cut with 24V in default)
Common port of X1 X6, PLC is
isolated from 24V internally
COM
Common port
of
24V power
supply
Three common ports in all, cooperate with other
terminals
COM is isolated from CME and
GND inside the drive
Relay
output
terminal 1
Ra
Relay output
Can be defined as multi-function relay
output terminal(Refer to the A6.16 for detail)
Ra-Rb.Normally closed
Ra-Rc.normally open
Contact capacity .
1)
0.4)
DC30V/1A
Input voltage for over-voltage
class of relay output terminal is
over-voltage class II
Rb
Rc
