Kinco FV20-4T-0037G/0055L User Manual

Chapter 2 Product introduction
43
Table 2-1 Mechanical parameters
VFD model
(G.Constant torque load;
L.Draught fan and water
pump load)
External dimension and (mm)
Weight
(kg)
W H D W1 H1 D1
Installation
hole(d)
FV20-4T-0007G/0015L
120 186 167 115 175 74.5 4.7 2
FV20-4T-0015G/0022L
FV20-4T-0022G/0037L
FV20-4T-0037G/0055L
FV20-4T-0055G/0075L
140 256 181 131 243 91 5.8 6
FV20-4T-0075G/0110L
FV20-4T-0110G/0150L
160 320 207 151 303 115 5.8 8
FV20-4T-0150G/0185L
FV20-4T-0185G/0220L
FV20-4T-0220G/0300L
206 471 201 166 453 94 7 18
FV20-4T-0300G/0370L
FV20-4T-0370G/0450L
320 535 224 220 512 88.5 10 31
FV20-4T-0450G/0550L
FV20-4T-0550G/0750L
373 649 262 240 628 102.5 10 42
FV20-4T-0750G/0900L
FV20-4T-0900G/1100L 440 758 285 340 737 102 11 73
FV20-4T-1100G/1320L
430 780 330 280 755 168 11 76
FV20-4T-1320G/1600L
FV20-4T-1600G/1850L
530 940 380 340 910 206 14 114 FV20-4T-1850G/2000L
FV20-4T-2000G/2200L
FV20-4T-2200G/2500L
690 1006 380 500 974 207 14 156 FV20-4T-2500G/2800L
FV20-4T-2800G/3150L
FV20-4T-3150G/3550L
810 1228 400 520 1196 209 14 225 FV20-4T-3550G/4000L
FV20-4T-4000G/4500L
FV20-4T-6000G
810 1328 400 520 1296 / 14 450
FV20-4T-8000G
FV20-4T-10000G 1480 1807 600
Pedestal installation
W1*H1=1040*440 d=14
460
