Spool
>
one of the same type or the trimming line must be
refilled.
If the line is used up the spool must either be replaced by
(22a)
WARNING! Only replace spool and/or trimming line
according to the technical specifications (see You
product ā Technical specificationā!
Never use metal thread!
Always use cutting attachments in perfect condition,
free of damage!
>
head facing upward.
> Remove the trimming head (22) by unscrewing the bumper
clockwise (Fig. 16a).
> Twist the spool (22b) slightly to open the trimming head
housing. The cover and spool will pop out (Fig. 16b).
Lay the product on a flat stable surface with the trimming
Fig.16a
Fig.16b
In more detail...
41
FPGTP25-2
Care and maintenance
Replacing the spool
> Remove the worn spool and replace with a new one of the
same type.
> Align the noses on the spool to the notches of the housing,
and then push und twist the spool onto the housing to close
the trimming head.
EN
