Refilling trimming line
>
line and insert this loop into the hook on the spool
(Fig. 16c).
> Wind the two parts of the trimming line in clockwise
direction firmly around the spool. Ensure each part of the
line is either side of the guide on the spool (Fig. 16d).
Cut a new trimming line. Form a loop at the middle of the
Fig.16c Fig.16d
>
holes. The line should stick out 200mm on each side.
> Refit the trimming head to the spindle as described in
section “Assembly – Trimming head”.
Insert each end of the trimming line in the respective
WARNING! After changing the trimming line, run the
product under no load for at least a minute to make
sure that the line and the product are operating
correctly!
In more detail...
42
FPGTP25-2
Care and maintenance
EN
