NMRS1500
Getting Started . . .
Assembly
1. Loosen screws (9) on both side, do not remove completely (Fig. 1).
Fig. 1
2. Align the lower hand bars (6) with the supports (8) (Fig. 2). Make sure the holes
in the lower handle bars face outwards and secure the bars with one screw (9) to
each support (8) (Fig. 3).
6
6
8
9
Fig. 2 Fig. 3
3. Align the middle handle bars (3) to the lower ones (6). Make sure the holes of the
handle bars (3, 6) correspond and secure them with handle assembly set (5) on
each side , make sure the locking knob is located inside. (Fig. 4&5).
Before you start
