22
NMRS1500
In more detail . . .
4. To change the cutting device (21), raise the bearing seat (23) then withdraw the
cutting device from the drive shaft.
5.
Remove the bearing seat (23) from the cutting device (21), and attach it onto a
new one. (Fig. 25)
6.
Align and insert the new cutting device: Slide the hex nut (built in the end of the
(23) to the support with the bolts (24a) and washers (24b) (Fig. 26).
The hex nut
Fig. 26
WARNING! For safety reasons, we recommend having the cutting device
WARNING! Always use an original cutting device recommended by the
manufacturer for replacement. Do not attach other types of cutting device.
Overload protection
The overload protection will be activated in the following circumstances:
1.
2.
3. Where there is too much resistance against the cutting device.
When the circuit breaker has been activated switch off the product and disconnect
from the power supply.
Let the product cool down and eliminate the cause before using the product again.
Product functions
