5. INSTALLATION
It is important that your appliance is installed and operated in accordance with
the manufacturers instructions to guarantee the performance, efficiency and
operation.
• Position the appliance in a safe and secure location. Limit exposure to
heat sources or direct sunlight which can affect the units’ performance
and efficiency.
• The normal operation of the appliance requires heat to be radiated away
from the condenser located in the rear end of the unit. Adequate airflow
is required to be available around the compressor at all times.
This appliance is designed to operate on AC and DC voltage inputs.
The device is equipped with a multi-level battery monitor that protects your vehicle battery against excessive discharging
when the appliance is connected to a 12/24V supply.
The fridge switches off if the input Voltage falls below the set value. The fridge will switch back on after a 60 Second delay,
once the input Voltage is above the set value, in the table below.
Push, hold and release button until the desired setting is reached.
6. POWER MANAGEMENT
AC INPUT 240V at 50Hz
DC INPUT 12V or 24V
7. BATTERY MONITOR/PROTECTION
BATTERY
PROTECTION
MODE INPUT POWER: 12V INPUT POWER: 24V
LOW
9.6V/OFF
10.9V/ON
21.3V/OFF
22.7V/ON
MED
10.1V/OFF
11.4V/ON
22.3V/OFF
23.7V/ON
HIGH
11.1V/OFF
12.4V/ON
24.3V/OFF
25.7V/ON
