3.3.9 Bluetooth function
The device is with built in Bluetooth function for configuration and sensors
connecting for example Bluetooth fuel sensor
4.1 Wiring diagram
Red LED:
FastBlink: GPRS connecting
Slow blink ： GPRS
connected
Solid on: Module error
Green LED:
Fast Blink:GPS Signal searching
Solid on:GPS fixed
Slow blink:LBS position
Off: GPS not fix
Battery Switch
SIM card slot
GPS antenna
PART 04
Installation guide
