Kingwo MT200 - Technical Specification

4
Physical
Dimension
75*40*13mm
Weight
45±3g
Cellular
GSM module
Quectel MC25
Frequency
Working Frequency:
850/900/1800/1900MHz
Network protocol: Embedded TCP/IP stack
Sensitivity: -107dBm@850/900MHz
-106dBm@1800/1900MHz
Output power: Class 4
(2W)@850/900MHz
Class 1
(1W)@1800/1900MHz
GPRS data: GPRS Class 10, Mobile Station
Class B
GPS
Channels: 50
Sensitivity: -147dBm
Position accuracy:5-10m
Accuracy: 5m CEP
Cold start: <27s
Hot start: <1s
Bluetooth
Bluetooth 5.0
Power
Input voltage
9-100V
Battery
NI-MH AAA 3.6V/90mA,2hours working
time based on 2-3 minutes upload
Power
consumption
Average Current: <30mA (DC 12V)
Maximum current: <10mA (DC 12V)
Interface
Digital input(2)
Ignition detect and Air condition status
detect
Digital output(1)
Relay
Analog input 1
Voltage range:0-36V
GSM antenna
Internal High Gain
GPS antenna
Internal High Gain
SIM
Microsim
PART 02
Technical Specification
