5-7 OPERATION
704O508C704O507C
8. INSERT THE KEY INTO THE KEY
SWITCH AND TURN IT “ON”.
This tractor has an automatic pre-heat-
ing system. To pre-heat the engine, turn
the key switch to the "ON" position then
pre-hearting works automatically for 8
seconds. You can see the pre-heating
indicator light on during that time. You
can start the engine at any time during
this 8 seconds.
(1) Clutch Pedal
9. DEPRESS THE CLUTCH PEDAL.
10. TURN THE KEY TO “START” PO-
SITION AND RELEASE WHEN
THE ENGINE STARTS.
If you need additional pre-heating, turn
the key off and try the same procedure
again or turn the key to "Manual pre-
heat" position and hold it. Do not pre-
heat over 15 seconds, more than 10
times without any break.
When the coolant temperature is over
60°C(140°F) the auto pre-heating
does not work. In this case, just turn
the key to "start" to crank the engine.
WARNING
!!
!!
!
zz
zz
z Do not operate the starter motor
continuously for more than 10
seconds.
zz
zz
z If the engine does not start; turn
the switch to “OFF”, wait 30
seconds, and repeat the starting
procedure.
zz
zz
z Never engage the starter motor
before the engine stops turning.
When ambient temperatures are
colder, a longer pre-heat time is
necessary.
NOTE
zz
zz
z The engine will not start unless
the range gear shift lever (Hi-Lo)
and the PTO clutch lever are in
the “OFF” position.
IMPORTANT
(1) Key Switch
( ) Off ( ) Manual Pre-Heat
( ) Acc ( ) Start
( ) On(Auto Pre-Heat)
