5-18 CK25/30/35
With a creeper transmission, an opera-
tor has the option to use 16 F and 16R
gears.
zz
zz
z To stop the tractor, be sure to
disengage the clutch first, then
depress the brake pedal. This is
because creep range gives high
torque at low forward speeds
thus making braking ineffective.
zz
zz
z To avoid any transmission
damage, do not convert from for-
ward to revere and vice versa
while driving.
!!
!!
!
CAUTION
1. Be sure the range gear shift lever is
in neutral position.
2. Release clutch pedal(Manual type)
or slightly depress the speed con-
trol pedal to rotate the gears inside
of transmission.(HST only) Release
the speed control pedal to neutral.
3. Depress clutch pedal and then shift
the range gear shift lever.
(4)CREEP GEAR SHIFT LEVER
(1) Creep Gear Shift Lever
(A) “HIGH” (N)“NEUTRAL”
(B) “LOW”
HOW TO USE CREEP GEAR SHIFT
LEVER
zz
zz
z To avoid transmission damage,
depress clutch pedal and stop
tractor before shifting between
ranges.
zz
zz
z In high shift ranges and low en-
gine rpm, the vehicle could be
stopped when the output axles
are loaded. At that time, Use the
low range gear or increase the
engine rpm.
zz
zz
z HST is very precise apparatus.
When using the tractor for long,
be sure to replace oil filters
regularly.
only EU-option
If you misuse or mishandle the creep-
ing speed, it may cause damage to
the unit, so please note the following.
1. Possible times to use;
• A deep tilling application
• When unable to maintain a constant
speed in harsh field conditions
• Transplanting
• When loading and unloading
704O526C
