5-19 OPERATION
(1) Range Gear Shift Lever (Hi-Lo)
H “HIGH SPEED”
N “NEUTRAL POSITION”
M “MIDDLE SPEED”
L “LOW SPEED”
704O527C
HST Type
(5) FRONT WHEEL DRIVE LEVER
The front wheel drive should always be
engaged when the tractor is stopped.
Shift the lever to the "ON" position to
engage the front wheel.
(1) Front Wheel Drive Lever
“ENGAGED” “DISENGAGED”
704O528C
