Kioti CS2520HS - Replacing FUSE (An)

7
-
34
CS2220H(S)/CS2520H(S)
Fuse panel is located under the right side of the instrument panel.
5
15
10
5
10
15
15
15
25
20
5A
15A
10A
5A
10A
15A
15A
15A
25A
20A
MEMORY
COMBIMETER
FLASHER
HORN
SAFETY
COMBIMETER
PREHEAT
CRUISE
START
SPARE 25A SPARE 20A
POWER SOCKET
STOP LAMP
HEAD LAMP
TAIL LAMP
ENGINE STOP
SOLENOID
tb2O709A
5
15
10
5
10
15
15
15
25
20
5A
15A
10A
5A
10A
15A
15A
15A
40A
40A
MEMORY
COMBIMETER
FLASHER
HORN
SAFETY
COMBIMETER
PREHEAT
CRUISE
START
SPARE 25A SPARE 20A
POWER SOCKET
STOP LAMP
HEAD LAMP
TAIL LAMP
ENGINE STOP
SOLENOID
tb3O718A
CS2220 CS2520
Fuses protect the tractor electrical
system from potential damage. A
blown fuse indicates that there is an
overload or short somewhere in the
electrical system.
(1) Fuse Box
tb2O713A
REPLACING FUSE (AN)
