a Maximum Lift Height 3,400mm 133.9 in
B Clearance with Attachment Level 3,123mm 123.0 in
c
Clearance with Attachment Dumped 2,599mm
102.3 in
d Reach at Maximum Height 45° 519mm 20.4 in
e Maximum Dump Angle 47° ←
f Reach with Attachment on Ground 2,043mm 80.4 in
G Attachment Rollback Angle 54° ←
H Digging Depth Below Grade
166mm
6.5 in
J Overall Height in Carry Position 1,760mm 69.3 in
L Depth of Attachment (to back of inner shell) 592mm 23.3 in
M Height of Attachment 581mm 22.9 in
n Depth of Attachment (to pivot pin) 838mm 33.0 in
S Lift Capacity to Full Height at Pivot Pins 1,535 kgf 3,384 lbs
t Breakout Force at Pivot Pins 2,431 kgf 5,359 lbs
Lift Cylinder ø70mmX572mm Ø2.8X23.2 in
Bucket Cylinder ø70mmX405mm Ø2.8X15.9 in
Bucket Width 2130mm 82 in
Bucket Weight 194 Kg 428 lbs
Approx. Weight (without Bucket) 666 Kg 1,468 lbs
Bucket Capacity 0.60
m
³ (0.38
m
³) 21.2 ft³ (13.2 ft³)
