STEP 6.
Install Front Grill. (Optional)
1. Front Grill - 1EA
2. Hex-Bolt, M16-1.5P 40L – 4EA
Spring-Washer, M16 – 4EA
STEP 5.
Install Rear Frame W.A, LH/RH.
8. Rear Frame W. A, LH – 1EA
9. Rear Frame W. A, RH – 1EA
10. Hex-Bolt, M16-P2.0 50L – 4EA
Spring-Washer, M16 – 4EA
Hex-Nut, M16-P2.0 – 4EA
11. Hex-Bolt, M14-P1.5 50L – 6EA
Spring-Washer, M14 – 6EA
601OE02B
1
2
(1) Front Grill (2) Bolt
To Next Page
