Kioti RX7320 - Page 63

PART ILLUSTRATIONS 13-7
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
ZTBU5-7800S-01
ZTBU5-7810N
ZTBU5-78200-01
14124-25110-N
14124-25138-N
14124-25122-N
1021M-M2404
ZTBU5-H700
FTF40-62102
ZTBU5-72301
1012S-M0803-35
226505
802L2-P46F9-42
802T2-F94F9-40
802N2-F94F9-40
81300-0P014
80620-01002
80620-01003
80620-07011
80420-T1130
80410-T1130
8043K-01100
8044K-01100
4in1 Bucket Ass'y, 78" (NO. 1~23)
Front Bucket W.A, 78", V-hump Type
Rear Bucket W.A-ISO Euro, 78"
Pin W.A, Ø25-110L
Pin W.A, Ø25-138L
Pin W.A, Ø25-122L
Nut-Selock, M24-P1.5
Pipe Ass’y, Ø12
Clamp
Cover, Pipe
Sem’s Bolt, M8-P1.25 35L
Cylinder, 30x50x415L(ST180)
Nipple, 3/4-16UNF, Hose x PF3/8, O-ring 90˚
Nipple, 3/4-16UNF, T-Hose
Nipple, 3/4-16UNF, Hose x 3/4-16UNF, Hose
O-ring, P14
Hose, 4(3/4-16UNF)-4(3/4-16UNF) 350L(3/8)
Hose, 4(3/4-16UNF)-4(3/4-16UNF) 550L(3/8)
Hose, 904(3/4-16UNF)-1(PT1/2) 1700L(3/8)
Quifk Coupler, PT1/2" Female
Quifk Coupler, PT1/2" Male
Dust Plug, 1/2" Black Male
Dust Cap, 1/2" Black Female
1
1
1
2
2
2
6
2
2
1
2
2
4
2
2
4
2
2
2
1
1
1
1
