PART ILLUSTRATIONS 13-11
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
1
2
3
4
5
6
7
8
9
10
11
FT116-G1000
FT116-11700
FT613-11600-02
10191-M1205-35
10321-M1200
1021N-M1205
14116-12086-01
LK01-0203
14031-04040
10191-M1604-40
10316-M1600
Grill Kit, NO.2~11
Grill, Outer
Grill, Inner
Hex-Bolt, M12-1.75P 35L
Plain-Washer, M12
Hex-Nut Lock, M12-1.75P
Pin, Ø12
Spring, Ø1.5
Spring-Pin, Ø4
Hex-Bolt, M16-1.5P 40L
Spring-Washer, M16
1
1
1
2
2
2
2
2
2
4
4
