PART ILLUSTRATIONS 13-19
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
FTF66-H0000
22D003
22D004
22D001
FTF66-H0101
1012S-M0803-35
801T1-50000
802N2-P46F9-42
802H1-F94F9-40
802L2-P46F9-42
81301-BP014
FTF39-HP100
FTF39-HP200
FTF39-HP300
FTF39-HP400
FTF39-HP500
FTF39-HP600
FTF39-HP700
FTF39-HP800
80620-01037
80620-03031
80620-01027
80620-03011
Hydraulic piping Kit, NO.1~26
Boom Cylinder Ass'y LH, Ø40-Ø70-905L (ST572)
Boom Cylinder Ass'y RH, Ø40-Ø70-905L (ST572)
Bucket Cylinder Ass'y, Ø35-Ø70-1080L (ST405)
Cover
Sem's Bolt, M8-P1.25-35L
Valve, Relife
Nipple, PF3/8, O-Ring x 3/4-16UNF, Hose
Nipple, 3/4-16UNF, Hose H-Type
Nipple, 3/4-16UNF, Hose x PF3/8, O-Ring 90˚
O-Ring, 1BP14
Pipe Ass’y
Pipe Ass’y
Pipe Ass’y
Pipe Ass’y
Pipe Ass’y
Pipe Ass’y
Pipe Ass’y
Pipe Ass’y
Hyd Hose, 4(3/4-16UNF)-4(3/4-16UNF) 1050L(3/8)
Hyd Hose, 4(3/4-16UNF)-2(3/4-16UNF) 1100L(3/8)
Hyd Hose, 4(3/4-16UNF)-4(3/4-16UNF) 450L(3/8)
Hyd Hose, 4(3/4-16UNF)-2(3/4-16UNF) 450L(3/8)
1
1
2
1
11
1
4
4
8
12
1
1
1
1
1
1
2
1
1
1
1
1
