Kioti RX7320 - Page 79

PART ILLUSTRATIONS 13-23
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
22D003
22D004
22D001
1012S-M0803-35
801T1-50000
802N2-P46F9-42
802H1-F94F9-40
802L2-P46F9-42
81301-BP014
FTF39-HP100
FTF39-HP200
FTF66-HP100
FTF66-HP200
FTF39-HP500
FTF39-HP600
FTF41-HP700
FTF39-HP800
80620-01037
80620-03031
80620-01027
80620-03011
80620-01026
80620-03010
Boom Cylinder Ass'y LH, Ø40-Ø70-905L (ST572)
Boom Cylinder Ass'y RH, Ø40-Ø70-905L (ST572)
Bucket Cylinder Ass'y, Ø35-Ø70-1080L (ST405)
Bolt-Sem's, M8x1.25P 35L
Valve, Relife
Nipple, PF3/8,O-Ring x 3/4-16UNF
Nipple, H-TYPE 3/4-16UNF, Hose
Nipple, PF3/8, O-Ring x 3/4-16UNF, Hose 90˚
O-Ring, 1BP14
Pipe Ass'y
Pipe Ass'y
Pipe Ass'y
Pipe Ass'y
Pipe Ass'y
Pipe Ass'y
Pipe Ass'y
Pipe Ass'y
Hyd Hose, 4(3/4-16UNF)x4(3/4-16UNF) 1050L(3/8)
Hyd Hose, 4(3/4-16UNF)x2(3/4-16UNF) 1100L(3/8)
Hyd Hose, 4(3/4-16UNF)x4(3/4-16UNF) 450L(3/8)
Hyd Hose, 4(3/4-16UNF)x2(3/4-16UNF) 450L(3/8)
Hyd Hose, 4(3/4-16UNF)x4(3/4-16UNF) 850L(3/8)
Hyd Hose, 4(3/4-16UNF)x2(3/4-16UNF) 850L(3/8)
1
1
2
15
1
4
4
8
12
1
1
1
1
1
1
2
1
1
1
1
1
3
1
