Kioti RX7320 - Page 81

PART ILLUSTRATIONS 13-25
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
24
25
26
27
27
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
FTF40-62102
FTF40-62101
801Z1-02000
802N0-T46P4-61
802N2-P46F9-41
802N2-P46F9-4M
802N2-F94T6-3S
802N2-F94T6-3S
80420-T1130
80410-T1130
8043K-01100
8044K-01100
103C0-C0330
80620-23008
80620-08010
FTF66-H0104
FTE44-H0036
FTF66-H0102
FTF66-H0103
10121-M0602-C0
10316-M0600
10211-M0602
1012S-M1004-25
Clamp
Clamp
Valve, DUKIN
Nipple, PF3/8, Copper×3/8
Nipple, PF3/8, Copper×3/4-16UNF, Hose
Nipple, PF3/8 Copper x 3/4-16UNF (69L)
Nipple, PF1/4(O-Ring)×1/2-20UNF(9O˚ Elbow)
Nipple, PF1/4(O-Ring)×1/2-20UNF(9O˚ Swivel)
Quick Coupler, PT1/2 Female
Quick Coupler, PT1/2 Male
Dust Plug, 1/2" Male Black
Dust Cap, 1/2, Black
Washer-Copper, 3/8"
Hyd Hose, 904(3/4-16UNF)x454(3/4-16UNF)1070L(3/8) 180˚
Hyd Hose, 904(3/4-16UNF)x2(3/4-16UNF) 1500L(3/8)
Cover, Pipe
Clamp
Cover, Valve
Plate, Solenoid Valve
Hex-Bolt, M6xP1.0-120L
Washer-Spring, M10
Hex-Nut, M6x1.0P
Bolt-Sem's, M10x1.5P 25L
1
4
1
4
4
2
2
2
1
5
1
1
6
2
2
1
2
1
1
2
4
4
2
13.04.11~
Wrong spec
