PART ILLUSTRATIONS 13-33
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
22D003
22D003-R
OC70-8037
IA70-4055
IC70-4055
DSSD-R040
UPSK-Y040
UPIS-I040
OR1B-G065
DU04-0020
PA70-2746
PI70-2746
OR1B-G027
UPOS-I070
TRBR-0070
WEWR-0070
NTP0-U100-C
22D003-T
Boom Cylinder Ass'y LH, NO.1~17
Rod Ass'y
Cap, Outer, Ø70x80x37L
Seal Kit Head, NO.4~9
Cover, Inner, Ø70x40x55L
Dust, SDR 40x48x5/6.5
Packing, U, SKY 40x50x6
Packing, U, ISI 40x50x6
O-Ring, 1BG65
Bushing, DU, 40x44x20
Seal Kit Piston, NO.11~15
Piston, Ø70x27x46L
O-Ring, 1BG27
Packing, U, OSI 70x60x6
Backup, Ring, 70x60x3
Wearing, WR 70x65x15
Nut, 1-14UN
Tube Ass'y
1
1
1
1
1
1
1
1
2
1
1
1
2
2
2
1
1
1
