Kioti RX7320 - Page 93

PART ILLUSTRATIONS 13-37
REF. NO PART. NO DESCRIPTION QTY I.C REMARK
13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
22D001
22D001-R
OC70-8040
IA70-3565
IC70-3565
DSSD-R035
UPSK-Y035
UPIS-I035
OR1B-P060
DU03-5030
PA70-2746
PI70-2746
OR1B-G027
UPOS-I070
TRBR-0070
WEWR-0070
NTP0-U100-C
22D001-T
Boom Cylinder Ass'y, NO.1~17
Rod Ass'y
Cap, Outer, Ø70x80x40L
Seal Kit Head, NO.4~9
Cover, Inner, Ø70x35x65L
Dust, SDR 35x43x5/6.5
Packing, U, SKY 35x45x6
Packing, U, ISI 35x45x6
O-Ring, 1BP60
Bushing, DU, 35x39x30
Seal Kit Piston, NO.11~14
Piston, Ø70x27x46L
O-Ring, 1BG27
Packing, U, OSI 70x60x6
Backup, Ring, 70x60x3
Wearing, WR70x65x15
Nut, 1-14UN
Tube Ass'y
1
1
1
1
1
1
1
1
2
1
1
1
2
2
2
1
1
1
