5 Maintenance
■ Check list before starting up
No. Items Qty.
Feeding or
replacement of
grease and
parts
Referen
ce page
1 Any troubles at previous day. － － —
2 Check cooling water quantity in radiator and feed 1
Water or
antifreeze
25
①Check engine oil level and feed 1 Engine oil 25
②Check hydraulic oil level and feed 1 Hydraulic oil 26
③Check oil level in fuel tank and feed 1 #0 diesel oil 26
④Check oil level in brake fluid cup and
feed
1 Brake fluid 26
3
Check engine
oil level at
each part and
feed
⑤Check cleaning fluid for windshields —
Cleaning agent
for windshields
26
①Pin at installation position of moving arm 2
②Pin at installation position of shovel 2
③Connecting pin of push-pull rod 1
④Rocker pin 3
⑤Bottom pin of dumper cylinder 1
⑥Connecting rod pin on lift cylinder 2
4
Grease filling
at working
machine part
of shovel
⑦Bottom pin of lift cylinder 2
26
5 Check grease filling on universal joint pin 3 27
6 Check grease filling on center pin 1 27
7 Check grease filling on connection shaft 1 27
8 Check grease filling on steering cylinder pin 2
Lubricant
27
9 Check license plate for any contamination or damages 1 — 27
10 Check all lamps and instrument — — 27
11 Check operation of horn 1 — 27
12 Check of rearview mirror 2 — 27
13 Check for any oil or water leakage — — 27
14 Check operation of steering wheel 1 — 27
15 Check tyre pressure, wear and tear, damages or loosened
bolts
4 — 28
16 Check cooling fan and engine oil cooling fan for block and
clean if any
— — 28
17 Check effective status of parking brake 1
24
— 28
18 Check effective status of brake pedal 1 — 28
19 Check and tighten all loosened bolts and nuts — — 28
20 Check electrical wiring for any disconnection, short circuit or
loosened joints.
— — 28
21 Cleaning of batteries, wirings and silencer — — 28
To Next Page
