8.2.2.4Stop normally closed
After Terminal is open （ high potential）,confirmed by Set Input Fault Delay, stop the alarm
immediately. Relevant set input faults LED light up.
8.3 Programmable output list
KP310_1.00 controller has two terminals（terminal 17、18） to customers to set different
parameters.
No.
Contents
Note
1
0—reserved
the function reserved
2
1— genset Stop
Output when genset in the “Stop ” state
3
2— genset Preheat
Output when genset in the “ Preheat ” state
4
3— genset start
Output when genset in the “start ” state
5
4— genset idle
Output when genset in the “ idle ” state
6
5— genset running
Output when genset in the “ norminal
running” state
7 6— genset electric parameters
normal
Output when genset voltage，frequency is
normal
8
7—system Warning alarm
Output when system Warning alarm
9
8—system delay stop alarm
Output when system delay stop alarm
10
9—system Stop alarm
Output when system delay alarm
11
10—system alarm
Output when system alarm
12
11—manual mode
Output when system in the “manual mode ”
13
12—Remote mode
Output when system in the “Remote mode ”
14 13—Oil filter overtime
Output when Oil filter overtime alarm
15 14—Fuel filter overtime
Output when Fuel filter overtime alarm
16 15—Air filter overtime
Output when Air filter overtime alarm
17 16—start failure
Output when genset start failure
Note: if Set Output 1 or Set Output 2 is set as “4— genset idle”, start idle Time or Stop idle
Time can’t be 0, otherwise there will be no idle output.
