Kirisun PT3600 Service Manual

PT3600 Service Manual
15
Appendix 2 Electronic Parts List
PT3600-01
No. Part No. Name Specifications Unit Qty Position Mark
1 2RW3-RP08110SNAX-B Volume Switch RP08110SNAX-V01-0037,A103, ROHS PCS 1 SW403
2 3CE3-EJ-2507-CCPAK Plug-in Earphone Socket 2.5,EJ-2507-CCPA PCS 1 J502
3 3CE3-ST212-35K Plug-in MIC Socket 3.5,ST212-3.5 PCS 1 J503
4 3SE3-RE08140AX-V01-A Encoder Switch RE08140AX-V01-0000,16P16, ROHS PCS 1 SW404
5 3ST3-454548 Plug-in Touch Switch 4.5*4.5*4.8 PCS 2 SW305,SW303
6 3ST3-SKHLLBA010 Plug-in Touch Switch SKHLLBA010 imported, 7.5*7.5*4.0 PCS 1 SW302
7 4SM7-6027-A40B Microphone
6.0mm, height 2.7mm, -40dB±2dB, all
direction, 2.2K, 2V(B6027AP402-65)
PCS 1 MK1
8 7GCM-050050010-J
378 Crystal Sponge
Cushion
Black foam, 5*5*1, double-sided self-adhesive
(on the bottom of crystal oscillator)
PCS 2
9 7GCJ-S1727-A
PT558 Earphone Socket
Gasket
PVC, 0.4mmTHK, double-sided self-adhesive PCS 1
10 7MHP-1010-15A-W 3208 PVC MIC Gasket Transparent PVC, 0.5mmTHK PCS 1
11 7MHP-1727-10A-JC 558 Potentiometer Gasket
Transparent PVC, single-sided self-adhesive,
0.35THK
PCS 2
12 5XT1-CSTCR-7R30G53 Chip Ceramic Resonator CSTCR7M30G53-R0 PCS 1 X301
13 5OT1-12R8-CEC3-0503 Chip TCXO
NT5032SA/NT5032SC,12.8MHz±2.5PPm,5.0*3.
2*1.6mm
PCS 1 X603
14 5FE1-BLM21P300S Chip EMI Control Filter 2012,BLM21P300S/BLM21PG300S(0149-05) PCS 4 L512,L513,L634,L636
15 5FE1-BLM11A221SPT Chip EMI Control Filter
1608,BLM11A221SPT/BLM18AG221S(0138-05
)
PCS 8 L208,L209,L402,L403,L520,L521,L635,L638
16 4PE1-16-F5 Chip LED 1608, green, H19-213SYGC PCS 1 LED303
17 4PE1-16-F2 Chip LED 1608, red, 19-21SUR/S530-A2/TR8 PCS 1 LED304
18 3ST1-SKRTLBE010 Chip Touch Switch SKRTLBE010,4.5*3.55*3.3mm(ALPS) PCS 1 SW304
19 2RS1-32-R47J Chip Resistor 3216,0.47±5% PCS 3 R523,R524,R525
20 2RS1-16-473J Chip Resistor 1608,47K±5% PCS 1 R288
21 2RS1-16-224J Chip Resistor 1608,220K±5% PCS 1 R448
22 2RS1-16-221J Chip Resistor 1608,220±5% PCS 1 R511
23 2RS1-16-153J Chip Resistor 1608,15K±5% PCS 1 R532
24 2RS1-16-105J Chip Resistor 1608,1M±5% PCS 1 R537
25 2RS1-16-104J Chip Resistor 1608,100K±5% PCS 1 R445
26 2RS1-16-102J Chip Resistor 1608,1K±5% PCS 1 R447
27 2RS1-16-000O Chip Resistor 1608,0 PCS 4 R449,C579,L639,R444
28 2RS1-10-823J Chip Resistor 1005,82K±5% PCS 1 R509
29 2RS1-10-822J Chip Resistor 1005,8.2K±5% PCS 3 R346,R366,R522
30 2RS1-10-683J Chip Resistor 1005,68K±5% PCS 6 R270,R286,R301,R513,R208,R209
31 2RS1-10-563J Chip Resistor 1005,56K±5% PCS 5 R373,R377,R379,R381,R534
32 2RS1-10-562J Chip Resistor 1005,5.6K±5% PCS 1 R546
33 2RS1-10-474J Chip Resistor 1005,470K±5% PCS 1 R300
34 2RS1-10-473J Chip Resistor 1005,47K±5% PCS 12
R255,R260,R370,R371,R425,R426,R427,R428,
R508,R547,R665,R666
35 2RS1-10-472J Chip Resistor 1005,4.7K±5% PCS 7 R323,R353,R356,R359,R362,R651,R655
36 2RS1-10-471J Chip Resistor 1005,470±5% PCS 1 R292
37 2RS1-10-470J Chip Resistor 1005,47±5% PCS 1 R510
38 2RS1-10-393J Chip Resistor 1005,39K±5% PCS 1 R512
39 2RS1-10-392J Chip Resistor 1005,3.9K±5% PCS 2 R283,R303
40 2RS1-10-334J Chip Resistor 1005,330K±5% PCS 2 R321,R535
41 2RS1-10-333J Chip Resistor 1005,33K±5% PCS 2 R354,R357
42 2RS1-10-332J Chip Resistor 1005,3.3K±5% PCS 1 R569
43 2RS1-10-331J Chip Resistor 1005,330±5% PCS 2 R536,R550
44 2RS1-10-273J Chip Resistor 1005,27K±5% PCS 1 R533
45 2RS1-10-272J Chip Resistor 1005,2.7K±5% PCS 7 R268,R277,R278,R374,R376,R378,R380
